0.5mm Fish Farming HDPE Geomembrane China Supplier Geomembrana HDPE 0.75mm

0.5mm Fish Farming HDPE Geomembrane China Supplier Geomembrana HDPE 0.75mm

Name; geomembrane Length; 1-6m Thickness; 0.3 -2 mm Color; Black, white, blue, customized products can be supported according to customer needs

Subclassification：

Geomembrane

Key words：

Geomembrane

Email：

WhatsApp：

Product Details

Name; geomembrane

Length; 1-6m

Thickness; 0.3 -2 mm

Material; HDPE, LDPE, PVC, LLDPE

Color; Black, white, blue, customized products can be supported according to customer needs

The manufacturing manner of geomembrane usually consists of the following steps:

Raw fabric preparation: Select superb polymer materials, such as polyethylene (HDPE), polypropylene (PP), etc., to put collectively and mix the raw materials.

Processing mixing: feeding raw supplies into an extruder or injection molding pc for processing and mixing, making them in a fluid state.

Extrusion molding: The processed aggregate is handed through an extruder and molded into a sheet or roll shape of a geotextile film.

Cutting and processing: According to remarkable specs and requirements, limit and approach the extruded geomembrane to meet the wishes of customers.

Quality inspection: Conduct terrific inspection on the produced geomembrane, such as average overall performance assessments such as tensile strength, put on resistance, and chemical corrosion resistance.

Packaging and delivery: After strict fantastic inspection, the geosynthetic film is packaged and provided to consumers or suppliers before than leaving the factory.

This is the extensively normal manufacturing device for geomembranes, and the precise manufacturing process can also moreover vary relying on the requirements of one-of-a-kind producers and products. I hope the above data can be really helpful to you. If you have any specific questions or prefer in addition information, please feel free to let me know.

Properties	Test Method	GMSH050	GMSH075	GMSH100	GMSH150	GMSH200
■ Thickness	ASTM D5199	0.50 mm	0.75 mm	1.00 mm	1.50 mm	2.00 mm
■ Density	ASTM D1505	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc
Tensile Properties
■ Yield strength ■ Break strength ■ Yield elongation ■ Break elongation	ASTM D6693 Type IV	7 kN/m 13 kN/m 12% 700%	11 kN/m 20 kN/m 12% 700%	15 kN/m 27 kN/m 12% 700%	22 kN/m 40 kN/m 12% 700%	29 kN/m 53 kN/m 12% 700%
■ Tear Resistance	ASTM D1004	62 N	93 N	125 N	187 N	249 N
■ Puncture Resistance	ASTM D4833	160 N	240 N	320 N	480 N	640 N
■ Stress Crack Resistance	ASTM D5397	500 hrs	500 hrs	500 hrs	500 hrs	500 hrs
■ Carbon Black Content	ASTM D1603	2.0%	2.0%	2.0%	2.0%	2.0%
■ Carbon Black Dispersion	ASTM D5596	For 10 different views:9 in Categories 1 or 2 and 1 in Category 3
■ Oxidative Induction Time (OIT)	ASTM D3895	100 min.	100 min.	100 min.	100 min.	100 min.
■ UV Resistance High Pressure OIT retained after 1600hrs	ASTM D5885	50%	50%	50%	50%	50%
Dimensions
■ Roll Width (m)		7	7	7	7	7
■ Roll Length (m)		420	280	210	140	105
